Processor : Intel® Core™ Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB

AI PC Category : AI-Powered Gaming PC

NPU : Integrated Intel® AI Boost, up to 13 TOPS

Graphics : NVIDIA® GeForce RTX™ 5070 Ti 12GB GDDR7, Boost Clock 2220MHz, TGP 140W, 992 AI TOPS

Chipset : Intel® HM870 Chipset

Memory : 2x 16GB CSODIMM DDR5-6400

Memory Slots : Two DDR5 CSODIMM slots, dual-channel capable

Max Memory : Up to 32GB DDR5-6400 offering

Storage : 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Support :

Up to two drives, 2x M.2 SSD

• M.2 2242 SSD up to 1TB

• M.2 2280 SSD up to 2TB

Storage Slot :

Two M.2 slots

• One M.2 2280 PCIe® 5.0 x4 slot

• One M.2 2280 PCIe 4.0 x4 slot

Card Reader : None

Optical : None

Audio Chip : High Definition (HD) Audio, Realtek® ALC3306 codec

Speakers : 4 stereo speakers, 2W x2 (woofers), 2W x2 (tweeters), optimized with Nahimic Audio, Smart Amplifier (AMP)

Camera : 5.0MP with E-shutter

Microphone : 2x, Array

Battery : 80Wh

Power Adapter : 400W Slim Tip (3-pin)

Special Features : AI Chip: LA3

DESIGN

Display : 16" WQXGA (2560x1600) OLED 500nits Glossy, 100% DCI-P3, 240Hz, DisplayHDR™ True Black 1000, Dolby Vision®, G-SYNC®

Touchscreen : None

Color Calibration : Factory Color Calibration

Keyboard : Per-key RGB Backlit, English

Touchpad : Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)

Case Color : Eclipse Black

Surface Treatment : Anodizing Sandblasting

Case Material : Aluminium (Top), Aluminium (Bottom)

Pen : Pen Not Supported

Dimensions (WxDxH) : 364.38 x 275.94 x 21.9-26.65 mm (14.35 x 10.86 x 0.86-1.05 inches)

Weight : Starting at 2.57 kg (5.67 lbs)

SOFTWARE

Operating System : Windows® 11 Home Single Language, Simplified Chinese / English

Bundled Software : Office Trial + Lenovo® AI Now

CONNECTIVITY

WLAN + Bluetooth : Wi-Fi® 7, 802.11be 2x2 + BT5.4

WWAN : Non-WWAN

Ethernet : 2.5GbE (RJ-45)

Standard Ports :

2x USB-A (USB 5Gbps / USB 3.2 Gen 1)

1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On

1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1

1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer and DisplayPort™ 2.1)

1x HDMI® 2.1, up to 8K/60Hz

1x Headphone / microphone combo jack (3.5mm)

1x Ethernet (2.5GbE RJ-45)

1x Power connector

Docking : Various docking solutions supported via Thunderbolt™ or USB-C®.

SECURITY & PRIVACY

Security Chip : Firmware TPM 2.0 Enabled

Fingerprint Reader : None

Other Security : E-shutter

SERVICE

Base Warranty : 1-year, Courier or Carry-in

Included Upgrade : 3Y Legion Ultimate Support -IPPREM (ESS)

ACCESSORIES

Bundled Accessories : 4 Switchable Keycaps

CERTIFICATIONS

Green Certifications : ErP Lot 3, RoHS compliant

Other Certifications : TÜV Rheinland® High Gaming Performance, TÜV Rheinland® Low Blue Light (Hardware Solution)
