APC Smart-UPS 1000VA, Rack Mount, LCD 230V with SmartConnect Port (SMC1000I-2UC)
MYR2188.00
Color
Brand: APC
){kind=link}
Get shipping estimates
| Country | ||
| State | ||
| Shipping Method | ||
|
|
||
| Presentation | Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. |
|---|
Run time for load WMin-max: 60-600 W | 5min 21s |
|---|---|
| Product or component type | Uninterruptible power supply (UPS) |
| Communication port type | SmartConnect Ethernet port |
|---|---|
| Software package | SmartConnect software for remote power monitoring feature availability varies by terms of use |
| Run Time | |
|---|---|
| Efficiency | |
| Battery type | Lead-acid battery |
| Extended runtime | 0 |
| Number of battery filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 3 h |
| Number of battery replacement quantity | 1 |
| Battery life | 4…6 year(s) |
| Replacement battery | |
| Battery charger power | 72 W rated |
| Provided equipment | Documentation CD Installation guide Rack mounting brackets USB cable |
|---|---|
| Number of power module | 0 |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| product web sub-family | Cloud-enabled monitoring |
| Redundant | No |
| Number of rack unit | 2U |
|---|---|
| Number of cables | 1 |
| Colour | Black |
| Height | 8.6 cm |
| Width | 43.2 cm |
| Depth | 40.6 cm |
| Net weight | 20.52 kg |
| Mounting location | Front |
| Mounting preference | Lower |
| Mounting mode | Rack-mounted |
| Two post mountable | 1 |
| USB compatible | Yes |
| Main Input Voltage | 230 V |
|---|---|
| Other Input Voltage | 220 V 240 V |
| Input Connection Type | IEC 320 C14 |
| Input voltage limits | 170...300 V adjustable 180...287 V |
| Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Main Output Voltage | 230 V |
|---|---|
| Other Output Voltage | 220 V 240 V |
| Rated power in W | 600 W |
| rated power in VA | 1000 VA |
| output connection type | 4 IEC 320 C13 2 IEC Jumpers |
| Harmonic distortion | Less than 5 % |
| Maximum configurable power in VA | 1000 VA |
| Maximum configurable power in W | 600 W |
| Transfer time | 6 ms typical : 10 ms maximum |
| UPS type | Line interactive |
| Wave type | Sine wave |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Product certifications | C-Tick CE GOST VDE UK PSTI |
|---|---|
| Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
| Acoustic level | 42 dBA |
|---|---|
| Heat dissipation | 46 Btu/h |
| Operating altitude | 0...10000 ft |
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -15…45 °C |
| Storage altitude | 0…15240 m |
| Relative humidity | 0…95 % |
| Storage Relative Humidity | 0…95 % |
| Control panel | Multifunction LCD status and control console |
|---|---|
| Free slots | 0 |
| Communication port support | SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
| Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
| Surge energy rate | 459 J |
|---|---|
| Noise suppression | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 24.1 cm |
| Package 1 Width | 58.4 cm |
| Package 1 Length | 54.6 cm |
| Package 1 Weight | 22.33 kg |
| Warranty | 2 years repair or replace |
|---|
