APC Smart-UPS, Line Interactive, 1000VA, Tower, 230V, 8x IEC C13 outlets, SmartConnect Port+SmartSlot, AVR, LCD (SMT1000IC)
MYR2788.00
Color
Brand: APC
){kind=link}
Get shipping estimates
| Country | ||
| State | ||
| Shipping Method | ||
|
|
||
Presentation Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Run time for loadWMin-max: 70-700 W5min 49sProduct or component type Uninterruptible power supply (UPS) Communication port type SmartConnect Ethernet port
SmartSlotSoftware package SmartConnect software for remote power monitoring feature availability varies by terms of use Run Time Efficiency Battery type Lead-acid battery Additional information Configurable for 220 : 230 or 240 nominal output voltage Extended runtime 0 Number of battery filled slots 0 Number of battery free slots 0 Battery recharge time 3 h Number of battery replacement quantity 1 Battery life 3…5 year(s) Replacement battery Battery charger power 88 W rated Provided equipment Cat 5 Ethernet cable
Installation guide
USB cableNumber of power module 0 Number of power module filled slots 0 Number of power module free slots 0 product web sub-family Cloud-enabled monitoring Redundant No Colour Black Height 21.9 cm Width 17.1 cm Depth 43.9 cm Net weight 19.4 kg Mounting location Front Mounting preference No preference Mounting mode Not rack-mountable Two post mountable 0 USB compatible No Main Input Voltage 230 V Other Input Voltage 220 V
240 VInput Connection Type IEC 320 C14 Input voltage limits 151...302 V adjustable
160...286 VNetwork frequency 50/60 Hz +/- 3 Hz auto-sensing Main Output Voltage 230 V Other Output Voltage 220 V
240 VRated power in W 700 W rated power in VA 1000 VA output connection type 8 IEC 320 C13
2 IEC JumpersHarmonic distortion Less than 5 % Maximum configurable power in VA 1000 VA Maximum configurable power in W 700 W Transfer time 6 ms typical : 10 ms maximum UPS type Line interactive Wave type Sine wave Output frequency 50/60 Hz +/- 3 Hz sync to mains Product certifications CE
EAC
RCM
VDE
UK PSTIStandards EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018Acoustic level 41 dBA Heat dissipation 100 Btu/h Operating altitude 0...10000 ft Ambient air temperature for operation 0…40 °C Ambient air temperature for storage -15…45 °C Storage altitude 0…15240 m Relative humidity 0…95 % Storage Relative Humidity 0…95 % Control panel Multifunction LCD status and control console Emergency power off Optional Free slots 1 Communication port support SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Surge energy rate 459 J Noise suppression Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 37.600 cm Package 1 Width 59.500 cm Package 1 Length 32.800 cm Package 1 Weight 22.770 kg Unit Type of Package 2 P12 Number of Units in Package 2 9 Package 2 Height 112.500 cm Package 2 Width 80.000 cm Package 2 Length 120.000 cm Package 2 Weight 216.525 kg Warranty 3 years repair or replace (excluding battery) and 2 years for battery
