PERFORMANCE

Processor

Intel Core i5-12500, 6C (6P + 0E) / 12T, P-core 3.0 / 4.6GHz, 18MB

Graphics

Integrated Intel UHD Graphics 770

Chipset

Intel B660

Memory

1x 8GB UDIMM DDR4-3200

Memory Slots

Two DDR4 UDIMM slots, dual-channel capable

Max Memory

Up to 64GB DDR4-3200

Storage

512GB SSD M.2 2280 PCIe 3.0x4 NVMe Opal 2.0

Optane Memory

None

Storage Support

Up to two drives, 1x 2.5"/3.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • 3.5" HDD up to 2TB • M.2 SSD up to 1TB

Card Reader

None

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek ALC623-CG codec

Speakers

None

Power Supply

260W 90%

DESIGN

Keyboard

USB Calliope Keyboard, Black, English

Mouse

USB Calliope Mouse, Black

Expansion Slots

• One PCIe 3.0 x1, low-profie (length < 167.65mm, height < 68.90mm)
• One PCIe 4.0 x16, low-profie (length < 167.65mm, height < 68.90mm)
• Two M.2 slots (one for WLAN, one for SSD)

Case Color

Black

Stand

None

Form Factor

SFF (7.4L)

Dimensions (WxDxH)

100 x 308 x 274.8 mm (3.9 x 12.1 x 10.8 inches)

Weight

Around 4.5 kg (9.9 lbs)

CONNECTIVITY

Ethernet

Integrated 100/1000M

WLAN + Bluetooth

Intel 9560 11ac, 2x2 + BT5.0

Front Ports

• 2x USB 3.2 Gen 1
• 1x USB-C 3.2 Gen 1 (support data transfer and 5V@3A charging)
• 1x headphone / microphone combo jack (3.5mm)
• 1x microphone (3.5mm)

Optional Front Ports (configured)

1x card reader

Rear Ports

• 2x USB 2.0
• 2x USB 3.2 Gen 1 (one supports Smart Power On)
• 1x VGA
• 1x HDMI 2.1 TMDS
• 1x DisplayPort 1.4
• 1x Ethernet (RJ-45)
• 1x line-out (3.5mm)

Optional Rear Ports (configured)

None

Monitor Cable

None

SECURITY & PRIVACY

Security Chip

Discrete TPM 2.0, TCG certified

Fingerprint Reader

No fingerprint reader

Physical Locks

• Kensington Security Slot, 3 x 7 mm
• Padlock Loop

Kensington Cable Lock

None

Smart Cable Clip

None

Chassis Intrusion Switch

None

SERVICE

Base Warranty

1-year, Depot

Included Upgrade

3Y Premier Support Upgrade from 1Y Courier/Carry-in (5WS0T36200)

CERTIFICATIONS

Green Certifications

• ENERGY STAR 8.0
• EPEAT Silver
• ErP Lot 3
• TCO Certified 9.0
• RoHS compliant

SOFTWARE

Operating System

Windows 11 DG Windows 10 Pro 64, English
