Connectivity:
USB Interface:USB Type A: 2 (Port 1: Wireless LAN, Firmware Update, Copy OSD Settings / Port 2: For Streaming Media Player with 2,000 mA Power Supply)
USB Type Mini-B: 1
Network:Wired LAN: N/A
Wireless: Optional (ELPAP10)
Analog Input:D-Sub 15Pin: N/A
5BNC: N/A
Digital Input:DVI-D: N/A
HDMI Type A: 2 (HDCP 2.2)
SDI: N/A
HDBaseT: N/A
Output Terminal:D-Sub 15Pin: N/A
Audio Input:Stereo Mini Jack: N/A
Audio Output:Stereo Mini Jack: 1
Control I/O:RS-232C: N/A
Remote Control Input: N/A
Adjustment Functions:
Picture In Picture:N/A
Aspect Mode:Yes
Frame Interpolation:Off / Low / Normal / High (2D and 3D Mode)
Start-Up Period:
Start-Up Period:Up to 19 seconds
Warm-up period: 30 seconds
Operating Temperature:
Operating Temperature:5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft)
5 - 30 °C <41 - 86 °F> (Over 2,286 m / 7,500 ft)
(20% - 80% humidity, No condensation)
Operating Altitude:
Operating Altitude:0 - 3,048 m <0 -10,000 ft>
3D Features:
3D Display:Yes
3D Format:Side by Side / Top and Bottom
3D Depth:-10 to +10
2D - 3D Conversion:N/A
Wireless Specifications (Wireless LAN):
Supported Speed for each Mode:IEEE 802.11g (2.4GHz): 11 Mbps
*3IEEE 802.11b (2.4GHz): 54 Mbps
*3IEEE 802.11n (2.4GHz): 130 Mbps
*3Wireless LAN Security:Quick Mode: WPA2-PSK
Advanced Mode: WPA/WPA2-PSK
Supported Connection Mode:Infrastructure, Access Point
Power Supply Voltage:
Power Supply Voltage:100 - 240 V AC +/- 10%, 50/60 Hz
