Printer TypeLaser
Print MethodElectrophotographic Laser Printer
Memory Capacity32 MB
Power Source220 - 240 V AC 50/60 Hz
Power Consumption (Average)PeakApprox. 1,080 W
PrintingApprox. 390 W at 25 ° C
CopyingApprox. 390 W at 25 ° C
Networked StandbyApprox. 1.5 WApprox. 2.4 W
ReadyApprox. 50 W at 25 ° C
Deep SleepApprox. 0.9WApprox. 1.4 W
Power OffApprox. 0.28 WApprox. 0.3 W
Dimensions (W x D x H)385 mm x 340 mm x 255 mm385 mm x 340 mm x 283 mm
Weights (with consumables)7.2 kg8.2 kg
Noise LevelSound PressurePrintingL pa m = 52 dB (A)
Sound PowerPrintingL wa d = 6.6 B (A)
TemperatureOperating10 to 32 ° C
Storage0 to 40 ° C
HumidityOperating20 to 80% (without condensation)
Storage35 to 85% (without condensation)
InterfaceUSBHi-Speed USB 2.0
It is recommended you use a USB 2.0 cable (Type A/B) that is no more than 2 metres long.
Wireless LANIEEE 802.11b/g/n (Infrastructure Mode/Ad-hoc Mode)
Laser NoticeClick here for details.

Document Size

ADF(automatic document feeder)Up to 10 pages
Scanner GlassOne sheet per time
Document SizeADFA4, Letter, Legal, Folio
Scanner GlassLength: Up to 300.0 mm
Width: Up to 215.9 mm
WeightADF65 to 90 g/m2
Scanner GlassUp to 2.0 kg

Print Media

Paper InputPaper TrayPaper TypePlain Paper, Recycled Paper
Paper SizeA4, Letter, Legal, Folio, A5, A5(Long Edge), B5, Executive
Width: 148 to 216 mm
Length: 148 to 355.6 mm
Paper Weight65 to 105 g/m2
Maximum Paper CapacityUp to 150 sheets of 80 g/m2 Plain paper
Paper OutputFace-Down Output TrayUp to 50 sheets of 80 g/m2 Plain Paper (face-down delivery to the face-down output paper tray)


Modem Speed14,400 bps (with Automatic Fallback)
Scanning WidthMax. 208 mm
Printing WidthMax. 208 mm
Greyscale8 bit/256 levels
ResolutionHorizontal8 dot/mm
VerticalStandard: 3.85 line/mm
Fine: 7.7 line/mm
Photo: 7.7 line/mm
Superfine: 15.4 line/mm
Speed Dial99 stations
Automatic Redial3 times at 5 minute intervals
Memory TransmissionUp to 400 pages
Out of Paper ReceptionUp to 400 pages


Copy WidthMax. 210 mm
Multiple CopiesStacks or Sorts up to 99 pages
Reduce/Enlarge25% to 400% (in increments of 1%)
ResolutionUp to 600 × 600 dpi
First Copy Out TimeLess than 16 seconds at 23 ° C / 230 V


TWAIN CompliantYes (Windows ® XP/ Windows Vista ® / Windows ® 7 / Windows ® 8 / Windows ® 8.1 / OS X v10.7.5, 10.8.x, 10.9.x)
WIA CompliantYes (Windows ® XP / Windows Vista ® / Windows ® 7 / Windows ® 8 / Windows ® 8.1)
ICA CompliantYes (OS X v10.7.5, 10.8.x, 10.9.x)
Colour DepthColour24 bit colour processing (Input)
24 bit colour processing (Output)
Greyscale8 bit colour processing (Input)
8 bit colour processing (Output)
ResolutionUp to 19,200 × 19,200 dpi (interpolated)
Up to 600 × 1200 dpi (optical) (from Scanner Glass)
Up to 600 × 600 dpi (optical) (from ADF)
Scanning WidthMax. 210 mm


ResolutionUp to 2400 × 600 dpi (HQ1200 technology)
Print SpeedUp to 20 pages/minute (A4 size)
Up to 21 pages/minute (LTR size)
First Print Out TimeLess than 10 seconds at 23 ° C / 230 V

Network (LAN)

LANYou can connect your machine to a network for Network Printing, Network Scanning, PC-Fax Send, PC-Fax Receive (Windows ® only) and Remote Setup.
Also included is Brother BRAdmin Light Network Management software.
ProtocolsIPv4ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port 9100, IPP, FTP Server, SNMPv1/v2c, HTTP Server, TFTP Client and Server, SMTP Client, ICMP, Web Services (Print/Scan)
IPv6NDP, RA, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port 9100, IPP, FTP Server, SNMPv1/v2c, HTTP Server, TFTP Client and Server, SMTP Client, ICMPv6, Web Services (Print/Scan)
Security ProtocolsWirelessSMTP-AUTH
Wireless Network SecurityWEP 64/128, WPA-PSK (TKIP/AES), WPA2-PSK (AES)
Wireless Network Setup Support UtilityAOSS™Yes
