All Specifications

Display

Brightness (ANSI lumens)             3500

Native Resolution            1080P (1920x1080)

Native Aspect Ratio         16:9

Contrast Ratio (FOFO)    10,000:1

Display Color      30-bit (1.07 billion colors)

Light Source       Lamp

Light Source Life               a. Normal 5000 hrs ,b. ECO 10000 hrs ,c. SmartEco 15000 hrs ,d. LampSave 15000 hrs

Optical

Throw Ratio        1.49~1.64

Zoom Ratio         1.1x

Lens       F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm

Projection Offset (Full-Height)   108%

Keystone Adjustment    1D, Vertical ± 40 degrees


Picture Modes  3D ,Bright ,Infographic ,Presentation ,sRGB ,User 1 ,User 2 ,Video

Compatibility

Input Lag              34 ms (1080p@60Hz)

Resolution Support         VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking

Horizontal Frequency     15K~102KHz

Vertical Scan Rate            23~120Hz

I/O Interface

PC in (D-sub 15pin)          PC in-1 (shared with component video)

Monitor out (D-sub 15pin)            (x1)

HDMI in                (x1) ,HDMI-1 (1.4a/HDCP1.4)

USB Type A         (x3) ,USB Type A-1 (2.0/Power Supply1.0A/Reader) ,USB Type A-2 (2.0/Power Supply1.5A/Reader) ,USB Type A-3 (2.0/Wireless Dongle)

USB Type Mini B               (x1) ,USB Type Mini B-1(service/Page up&down)

RS232 in (DB-9pin)          (x1)

Audio

Speaker (x1) ,2W

Audio in (3.5mm Mini Jack)          (x1)

Audio out (3.5mm Mini Jack)       (x1)

Environment

Operating Temperature 0~40℃

Power Supply    AC 100 to 240 V, 50/60 Hz

Typical Power Consumption (110V)          270W/110V

Stand-by Power Consumption    <0.5W

Acoustic Noise (Typ./Eco.)(dB)   33/29 dB

Accessories

Wireless USB dongle       WDR02U

Carry Bag             (optional),5J.J3T09.001

Remote Control w/ Battery          RCI023

Power Cord (by region) x1 (1.8M)

VGA(D-sub 15pin) Cable (Standard) ,1 (1.5m)

3D Glasses          (Optional) ,DGD5

Quick Start Guide             (x1) 21L

Warranty Card (by region)            Yes

Universal Ceiling Mount (Optional) ,CMG3

Onscreen Display

Launcher             Smart Business

Smart System

Built-in OS           Yes, Android 6.0

Bluetooth            Yes, Bluetooth 4.0

Wi-Fi Standard  802.11 a/b/g/n/ac (2.4G/5G)

Wireless Projection         Google Cast

Dimension & Weight

Dimensions (WxHxD) (mm)         296 x120 x232

Net Weight (kg) 2.5 kg(5lbs)

Net Weight (lb) 5

Projection System

Projection System           DLP
