PERFORMANCE

Processor

Intel Core i5-12400, 6C (6P + 0E) / 12T, P-core 2.5 / 4.4GHz, 18MB

Graphics

Integrated Intel UHD Graphics 730

Chipset

Intel B660

Memory

1x 8GB UDIMM DDR4-3200

Memory Slots

Two DDR4 UDIMM slots, dual-channel capable

Max Memory

Up to 32GB DDR4-3200

Storage

512GB SSD M.2 2280 PCIe 3.0x4 NVMe

Optane Memory

None

Storage Support

Up to two drives, 1x 3.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB

Card Reader

None

Optical

9.0mm DVD±RW

Audio Chip

High Definition (HD) Audio, Realtek ALC623-CG codec

Speakers

No speakers

Power Supply

260W 90%

DESIGN

Keyboard

USB Calliope Keyboard, Black, English

Mouse

USB Calliope Mouse, Black

Expansion Slots

• One PCIe 4.0 x1, full height
• One PCIe 4.0 x16, full height
• Two M.2 slots (one for WLAN, one for SSD)

Case Color

Cloud grey

System Fan

1x Rear

Form Factor

Tower (13.6L)

Dimensions (WxDxH)

145 x 287.9 x 340 mm (5.71 x 11.33 x 13.39 inches)

Weight

5.4 kg (11.9 lbs)

CONNECTIVITY

Ethernet

Integrated 100/1000M

WLAN + Bluetooth

11ac, 2x2 + BT5.0

Front Ports

• 1x USB 3.2 Gen 1
• 1x USB 3.2 Gen 2
• 1x USB-C 3.2 Gen 1 (support data transfer and 5V@3A charging)
• 1x headphone / microphone combo jack (3.5mm)

Rear Ports

• 4x USB 2.0
• 1x VGA
• 1x HDMI 2.0b
• 1x Ethernet (RJ-45)
• 1x headphone (3.5mm)
• 1x power connector

SECURITY & PRIVACY

Security Chip

Firmware TPM 2.0 integrated in chipset

SERVICE

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

3Y Premium Care - Idea DT (ESS) (5WS0X58219)

CERTIFICATIONS

Green Certifications

• ErP Lot 3
• RoHS compliant

SOFTWARE

Operating System

Windows 11 Home 64 Single Language, Simplified Chinese / English

Bundled Software

Office Home & Student 2021
